AC3

AC3‐MP‐48X550

Output: Output Voltage Up to 47V

Output Current: 0.35A

Output connector: RJ45, 48 channels

Efficiency(Typ, 48V INPUT): 86%

Input voltage: 24~48V DC

Input current max: 17A

Input connector Power: 8PIN terminal block,

Data:RJ45

DMX Protocol: DMX512 ASTERA Protocols: ASTERA250, ASTERA500

Operating temperature: 20~50°C

Storage temperature: 20~80°C

Relative humidity: 0% ‐ 80%

Size(LxWxH): 120 x 145 x 187mm (4.7 x 5.7 x 7.4”)

Housing: Aluminium sheet IP level: IP20, Indoor
